Sourire Posted May 21, 2016 Author Report Share Posted May 21, 2016 Chez le préparateur reconnu Owens (buddy) Quote Link to comment Share on other sites More sharing options...
998engine Posted May 21, 2016 Report Share Posted May 21, 2016 ça va encore envoyer du gros. Quote Link to comment Share on other sites More sharing options...
Sourire Posted May 25, 2016 Author Report Share Posted May 25, 2016 Quote Link to comment Share on other sites More sharing options...
cooper66 Posted May 25, 2016 Report Share Posted May 25, 2016 c'est quoi cette culasse 16V ? Quote Link to comment Share on other sites More sharing options...
Sourire Posted May 25, 2016 Author Report Share Posted May 25, 2016 http://mk1-forum.net/viewtopic.php?f=4&t=2675&sid=5b16bc5ef0902cc992fffee4ef24238e http://www.racing70s.pwp.blueyonder.co.uk/racing70s/bmcsaloons/mini_065.htm Mini 850cc BDA EngineOne engine of this type came about by accident, literally! A 1300 BDA engine, fitted to a Mini, blew up and destroyed two cylinders. The two good cylinders were cut from the engine and used to produce a two cylinder engine by means of special blanking plates and crankshaft. At first the engine did not put out much power but when its problems were sorted it put out 115bhp, over 35bhp more than any engine of its size.Gordon Allen's Mini 850cc BDA EngineUnlike the other 850cc BDA mention above, this unit was a purposely designed two cylinder engine built for racing Minis. A specially manufacture alloy block and forged steel crank formed the basis of this engine. Bores were 85mm diameter and the stroke 74mm, giving it 848cc. A halved, standard Formula Atlantic BDA head with full size valves giving an 11.8:1 compression ratio was employed, and this was fed by a single 45DCOE Weber. The engine was mounted on a Mini transmission using an adaptor plate. Early versions of the engine gave an extra 20bhp over a standard racing 850cc A Series, this difference nearly double in the next 5 years. Quote Link to comment Share on other sites More sharing options...
Sourire Posted June 6, 2016 Author Report Share Posted June 6, 2016 Quote Link to comment Share on other sites More sharing options...
Sourire Posted June 7, 2016 Author Report Share Posted June 7, 2016 Montage pompe à eau électrique David Craig par le dry deck Quote Link to comment Share on other sites More sharing options...
Sourire Posted June 9, 2016 Author Report Share Posted June 9, 2016 Quote Link to comment Share on other sites More sharing options...
Sourire Posted June 9, 2016 Author Report Share Posted June 9, 2016 Quote Link to comment Share on other sites More sharing options...
Sourire Posted June 9, 2016 Author Report Share Posted June 9, 2016 Pipe d'admission Swan neck Quote Link to comment Share on other sites More sharing options...
PiOnPiOn Posted June 9, 2016 Report Share Posted June 9, 2016 col de cygne qui porte bien son nom, au moins le carbu est bien a l'horizontale Quote Link to comment Share on other sites More sharing options...
Sourire Posted June 9, 2016 Author Report Share Posted June 9, 2016 Oui sans découpe et admet des cornets un peu plus long (20 ou 30mm je pense) Quote Link to comment Share on other sites More sharing options...
998engine Posted June 9, 2016 Report Share Posted June 9, 2016 ah ça m'intéresse ce montage, quid du faisceau du break qui passe aussi ici. Je vais étudier ça. Quote Link to comment Share on other sites More sharing options...
Sourire Posted June 9, 2016 Author Report Share Posted June 9, 2016 Et la snaw neck sur un small block de mini donne de bons résultats il me semble, faut relire le site de graham Russel Quote Link to comment Share on other sites More sharing options...
998engine Posted June 9, 2016 Report Share Posted June 9, 2016 je regarderais à ça et je regarderais si je pars sur un twin HIF38 ou 44 maison ou sur un Weber 40 ou 45. Quote Link to comment Share on other sites More sharing options...
Sourire Posted June 9, 2016 Author Report Share Posted June 9, 2016 1293, le weber 40 suffit car il peut être buser jusqu'a 36. Quote Link to comment Share on other sites More sharing options...
998engine Posted June 9, 2016 Report Share Posted June 9, 2016 oui c'est ce que je viens de voir sur le site de Graham Russel Quote Link to comment Share on other sites More sharing options...
Sourire Posted June 9, 2016 Author Report Share Posted June 9, 2016 Quote Link to comment Share on other sites More sharing options...
998engine Posted June 9, 2016 Report Share Posted June 9, 2016 t'es pas cool j'ai commencé à chercher pour faire évoluer le break :ph34r: :ph34r: :ph34r: :ph34r: :ph34r: :ph34r: Quote Link to comment Share on other sites More sharing options...
Sourire Posted June 9, 2016 Author Report Share Posted June 9, 2016 Je mets pas tout ce que je trouve, je suis tombé sur un blog japonais, j'ai du coup envie de monter une mini .... c'est pas bon signe Quote Link to comment Share on other sites More sharing options...
998engine Posted June 9, 2016 Report Share Posted June 9, 2016 Je mets pas tout ce que je trouve, je suis tombé sur un blog japonais, j'ai du coup envie de monter une mini .... c'est pas bon signe :D :D :D :D :D Quote Link to comment Share on other sites More sharing options...
cooper66 Posted October 30, 2016 Report Share Posted October 30, 2016 Quote Link to comment Share on other sites More sharing options...
carbone Posted October 31, 2016 Report Share Posted October 31, 2016 hello les petits mecs,la pipe col de cygne,j'en ai eu une,bien pour la place mais pas assez direct pour l'admission. Quote Link to comment Share on other sites More sharing options...
Sourire Posted October 31, 2016 Author Report Share Posted October 31, 2016 Pascal, tu as déjà testé sur ta mini avec la configuration actuelle ? Car sur petite cylindrée, d'après Russel, ça fonctionne plutôt bien voir mieux. Quote Link to comment Share on other sites More sharing options...
cooper66 Posted October 31, 2016 Report Share Posted October 31, 2016 sur 1000 ou 1100, les 1300 c'est pas le mieux Pour ceux que ça intéresse, le sujet vu par un des plus grand préparateurs de A serie : http://russellengineering.com.au/project-small-bore-pt2/ Il y parle des pipes d'admissions avec des chiffres à l'appui. Quote Link to comment Share on other sites More sharing options...
